CNC - 2000 / 2500 / 3000
Compact yet powerful CNC-controlled diamond wire saw designed for quarries and stone processors. Features dual-head configuration with independent tensioning for superior cut quality and minimal kerf loss.
Technical Specifications
Max Processing Size (mm)
CNC-2000: 2000 × 3000 × 1500 (78.74 × 118.11 × 59.06 in)
CNC-2500: 2500 × 3000 × 1500 (98.43 × 118.11 × 59.06 in)
CNC-3000: 3000 × 3000 × 1500 (118.11 × 118.11 × 59.06 in)
Trolley Size (mm)
CNC-2000: 1300 × 2500 (51.18 × 98.43 in)
CNC-2500: 1300 × 2500 (51.18 × 98.43 in)
CNC-3000: 1300 × 2500 (51.18 × 98.43 in)
Main Motor (kW)
CNC-2000: 5.5
CNC-2500: 5.5
CNC-3000: 5.5
Wire Speed (m/min)
CNC-2000: 20 – 30
CNC-2500: 20 – 30
CNC-3000: 20 – 30
Outline Dimension (mm)
CNC-2000: 6800 × 6200 × 3800 (267.72 × 244.09 × 149.61 in)
CNC-2500: 7800 × 6200 × 3800 (307.09 × 244.09 × 149.61 in)
CNC-3000: 8800 × 6200 × 3800 (346.46 × 244.09 × 149.61 in)
Gross Weight (kg)
CNC-2000: 5000
CNC-2500: 5500
CNC-3000: 6000
Water Consumption (m³/h)
CNC-2000: 3
CNC-2500: 3
CNC-3000: 3
Machine in Action
Why Choose Us
-
Advanced PLC Control
Sophisticated CNC system with real-time load monitoring optimizes wire tension and feed rate automatically.
-
Dual Motor Tensioning
Independent motors for each cutting head deliver balanced tension across the entire cutting path.
-
Precision Water Management
Smart coolant circulation maintains optimal temperature for extended wire life and edge quality.
Industrial Versatility
Ideal for marble quarries, granite processing facilities, and stone distributors requiring high-volume slab cutting with minimal waste.
